Automatic Continuity Cable Tester

Eriwire Low Voltage Automatic Cable Tester, with 128 testpoints, Diode Test, Continuity Test.

Automatic Harness Cable Tester

Eriwire Low voltage Cable & Harness Tester

 The Cable & Harness Tester is an advanced testing solution designed for testing and validating the electrical connectivity of cables and harnesses. It features 128 testing points (TPs) and an insertion mode, which allows for quick and easy testing of cables and harnesses.

Insertion Mode, Guide mode Assembly Mode

Easy guide assembly connector, and avoid mistake or errors in the insertion process of the Harness Tester.

Continuity Cable Tester Wirelist

Verify the Wirelist of the Cable & Harness

With the 7 inches capacitive touch screen, it is easy and fast check and save your wirelist in the Harness Tester.

Features

128 Test Points

128 Test Points

128 Test Points

Automatic Continuity Cable Tester

High Quality Connector of 64 Test Points, Maximum 128 Test Points.

Continuity Test

128 Test Points

128 Test Points

Testing Continuity, Isolation and Shorts, Automatic Cable Tester Eriwire

Efficient algorithm allows the Eriwire Test faster and accurately Continuity Test.

Isolation Test

128 Test Points

Isolation Test

Testing Continuity, Isolation and Shorts, Automatic Cable Tester Eriwire

Test Isolation easy and faster Diodes, Netlist and Wires.

Diode Test

Intermittent Test

Isolation Test

Diode Test, Verify the correct polarity of the component.

Intermittent Test

Intermittent Test

Intermittent Test

Testing Continuity, Isolation and Shorts, Automatic Cable Tester Eriwire

Avoid bad connections with the option of intermittent Test.

Import CSV

Intermittent Test

Intermittent Test

Create your Wirelist on the excel sheet and import to the equipment.

Quick guide learning process of cable & harness Tester



Learn Process

 Cable Continuity Tester: This user-friendly tester is the optimal way to operate the equipment. By connecting the cable to the tester and pressing the ‘Learn’ button, you can quickly learn the wirelist. The machine will display information about the number of diodes, netlists, and wires associated with the cable or harness.


Testing Process

 After saving the wirelist into the machine, we can load the file and perform the test.

The Tester Performs the test the following sequence:

  • Continuity Test
  • Isolation Test
  • Extra Connection

Testing Cables, Harnesses, and Components with the Eriwire Harness Tester: The Eriwire harness tester is equipped with the capability to learn and test diodes and netlists. When attempting to learn a cable or harness, it’s possible that the cable contains diodes or netlists (splices).



Eriwire Low Voltage Cable Tester is a comprehensive solution for cable and harness testing. It is capable of performing a variety of tests to ensure the highest quality and performance of your cables and harnesses.

  • Diode (Polarity) Testing: This feature ensures that the diodes in your cable or harness are properly oriented and functioning, guaranteeing the correct flow of current.
  • Continuity Testing: Our tester verifies the integrity of the electrical connections in your cables and harnesses, ensuring reliable and consistent performance.
  • Electrical Shorts Testing: This feature detects any short circuits in your cable or harness, preventing potential damage and ensuring safety.
  • Miswires Testing: Our tester checks for any incorrect wiring that may affect the performance of your cable or harness, ensuring that every wire is correctly placed. With the Eriwire Low Voltage Cable Tester, you can be confident in the quality and performance of your cables and harnesses.

Testing Continuity, Isolation and Shorts, Automatic Cable Tester Eriwire

GUI Software

Eriwire editor software

GUI Connector Editor

Edit images and import to the tester easy and fast.

GUIDE Assembly Video

Eriwire Automatic Cable Tester, Guide Assembly

Eriwire automatic cable harness tester

    Eriwire User Manual

    User Manual

    User Manual for Eriwire Automatic Continuity Cable Tester
